Unidrive HS30 - AC drive (0.25 kW – 7.5 kW or 0.33 - 10 HP)



Flexible integration with safety and communications

0 – 3,000 Hz Open Loop

0.25 kW – 7.5 kW (0.33 hp – 10 hp)

200 V / 400 V

Unidrive HS30 is designed for applications that require cost effective integration into safety systems and incorporates dual Safe Torque Off and advanced Rotor Flux Control (RFC-A) of open loop induction motors

Features:

Conform to safety standards, maximize uptime and reduce costs by integrating directly with safety systems
  • HS30 has integrated dual STO inputs for SIL3, PLe conformity, eliminating the need for external safety components
Improve throughput with advanced open-loop motor control algorithms
  • Rotor Flux Control (RFC-A) gives maximum stability and control of induction motors at all powers.
  • 180% motor overload suitable for heavy industrial machinery applications
Flexible system integration with SI communications options
  • HS30's SI interface enables integration with a wide range of available industry standard fieldbuses and I/O
Install and configure quickly and easily
  • Simple fixed LED keypad
  • Useful parameter guide located on the front of the drive
  • Use Unidrive M Connect or an SD card with the AI-Backup adaptor to clone and transfer parameter sets
  • DIN rail mounting is supported below 1.5 kW

Specifications:

Key data
  • Heavy Duty rating: 0.25 - 7.5 kW (0.33 - 10 hp)
  • Supply phases:
    • Size 1 to 4: 110 V drives – 1 phase, 230 and 400 V drives - 1 or 3 phase
Standard features

Machine safety:
  • 2 x Safe Torque Off terminals
Keypad:
  • Fixed LED
Option slots:
  • 1 (Size 2 and above)
Parameter cloning via:
  • PC tools
  • SD card with AI-Smart Back Up
  • AI-Smart Adaptor

Voltage ratings
100 V (100 V - 120 V ± 10%)

200 V (200 V - 240 V ± 10%)
400 V (380 V - 480 V ± 10%)
575 V (500 V - 575 V ± 10%)

690 V (500 V - 690 V ± 10%)


Control mode
Open loop vector or V/Hz induction motor control
Open loop Rotor Flux Control for induction motors (RFC-A)
Open loop permanent magnet motor control (RFC-S)

Closed loop Rotor Flux Control for induction motors (RFC-A)

Closed loop permanent magnet motor control (RFC-S)

Active Front End (AFE) power quality convertor




frame size

Dimensions (h X w x d)
Weight

mm
in
kg
lb
1
160 x 75 x 130
DIN rail mounting*
137 x 75 x 130
6.3 x 3.0 x 5.1
DIN rail mounting*
5.4 x 3.0 x 5.1
0.75 1.65
2
205 x 75 x 150
DIN rail mounting*
180 x 75 x 150
8.1 x 3.0 x 5.9
DIN rail mounting*
7.1 x 3.0 x 5.9
1.0 2.2
3
226 x 90 x 160 8.9 x 3.5 x 6.3 1.5 3.3
4
277 x 115 x 175 10.9 x 4.5 x 6.9 3.13 6.9

*Additional fixings required to maximize security

Options:

Keypad
Remote keypad
All the features of the CI-Keypad LCD, but remote mountable. This allows flexible mounting on the outside of a panel and meets IP66 (NEMA 4)
System Integration Modules - Communications
SI-PROFIBUS
PROFIBUS interface module
SI-DeviceNet
DeviceNet interface module
SI-CANopen
CANopen interface module.
SI-Ethernet
External Ethernet module that supports EtherNet/IP and Modbus TCP/IP
SI-EtherCAT
EtherCAT interface module
SI-PROFINET
PROFINET interface module
System Integration Modules - Additional I/O
SI-I/O
Extended I/O interface module to increase the number of I/O points on a drive
Drive interface units - Back-up
AI-Back-up Adaptor
Port adaptor for SD card parameter cloning, and an input for 24 V back-up
AI-Smart Adaptor
Has built in memory for parameter cloning, and an input for 24 V back-up.
Drive interface units - Communications
AI-485 Adaptor
Port adaptor that allows the drive to communicate via RS485
CT USB Comms Cable
The USB Comms cable allows the drive to connect to a PC for use with Unidrive M's PC tools.*
*Also requires an adaptor.

Software:

Commissioning and monitoring software

Unidrive M Connect - Commissioning tool
Based on Control Techniques’ 25 years' experience, Unidrive M Connect is our latest drive configuration tool for commissioning, optimizing and monitoring drive/system performance


Unidrive HS30

High-Speed (Up to 3,000 Hz) Open Loop Induction/Rotor Flux Control (RFC-A) and Dual Safe Torque Off Channels

230 Vac, Single Phase Input, 3 Phase Output, 50/60 Hz Input

Normal Duty Heavy Duty Order Code Dimensions

H X W X D (in)

Weight (lbs) Require External AC Line Reactor
HP Amps HP Amps
0.33 1.7 0.33 1.7 HS30-01200017A10101AB100 6.3 X 3.0 X 5.1 1.7 N/A
0.5 2.4 0.5 2.4 HS30-01200024A10101AB100 6.3 X 3.0 X 5.1 1.7
0.75 3.3 0.75 3.3 HS30-01200033A10101AB100 6.3 X 3.0 X 5.1 1.7
1 4.2 1 4.2 HS30-01200042A10101AB100 6.3 X 3.0 X 5.1 1.7
0.5 2.4 0.5 2.4 HS30-02200024A10101AB100 8.1 X 3.0 X 5.9 2.2
0.75 3.3 0.75 3.3 HS30-02200033A10101AB100 8.1 X 3.0 X 5.9 2.2
1 4.2 1 4.2 HS30-02200042A10101AB100 8.1 X 3.0 X 5.9 2.2
1.5 5.6 1.5 5.6 HS30-02200056A10101AB100 8.1 X 3.0 X 5.9 2.2
2 7.5 2 7.5 HS30-02200075A10101AB100 8.1 X 3.0 X 5.9 2.2
3 10 3 10 HS30-03200100A10101AB100 8.9 X 3.5 X 6.3 3.3
3 13.3 3 13.3 HS30-04200133A10101AB100 10.9 X 4.5 X 6.9 6.9

230 Vac, 3Phase Input and Output,  50/60 Hz Input

Normal Duty Heavy Duty Order Code Dimensions

H X W X D (in)

Weight (lbs) Require External AC Line Reactor
HP Amps HP Amps
0.5 2.4 0.5 2.4 HS30-02200024A10101AB100 8.1 X 3.0 X 5.9 2.2 N/A
0.75 3.3 0.75 3.3 HS30-02200033A10101AB100 8.1 X 3.0 X 5.9 2.2
1 4.2 1 4.2 HS30-02200042A10101AB100 8.1 X 3.0 X 5.9 2.2
1.5 5.6 1.5 5.6 HS30-02200056A10101AB100 8.1 X 3.0 X 5.9 2.2
2 7.5 2 7.5 HS30-02200075A10101AB100 8.1 X 3.0 X 5.9 2.2
3 10 3 10 HS30-03200100A10101AB100 8.9 X 3.5 X 6.3 3.3
3 13.3 3 13.3 HS30-04200133A10101AB100 10.9 X 4.5 X 6.9 6.9
5 17.6 5 17.6 HS30-04200176A10101AB100 10.9 X 4.5 X 6.9 6.9

460 Vac, 3Phase Input and Output,  50/60 Hz Input

Normal Duty Heavy Duty Order Code Dimensions

H X W X D (in)

Weight (lbs) Require External AC Line Reactor
HP Amps HP Amps
0.5 1.3 0.5 1.3 HS30-02400013A10101AB100 8.1 X 3.0 X 5.9 2.2 N/A
0.75 1.8 0.75 1.8 HS30-02400018A10101AB100 8.1 X 3.0 X 5.9 2.2
1 2.3 1 2.3 HS30-02400023A10101AB100 8.1 X 3.0 X 5.9 2.2
1.5 3.2 1.5 3.2 HS30-02400032A10101AB100 8.1 X 3.0 X 5.9 2.2
2 4.1 2 4.1 HS30-02400041A10101AB100 8.1 X 3.0 X 5.9 2.2
3 5.6 3 5.6 HS30-03400056A10101AB100 8.9 X 3.5 X 6.3 3.3
3 7.3 3 7.3 HS30-03400073A10101AB100 8.9 X 3.5 X 6.3 3.3
5 9.4 5 9.4 HS30-03400094A10101AB100 8.9 X 3.5 X 6.3 3.3
7.5 13.5 7.5 13.5 HS30-04400135A10101AB100 10.9 X 4.5 X 6.9 6.9
10 17 10 17 HS30-04400170A10101AB100 10.9 X 4.5 X 6.9 6.9

Frame sizes 1 -3 do not include an internal reactor.

Ratings are at 3 kHz switching frequency. For ratings other than 3 kHz refer to appropriate User Guide.

© 2015 Emerson Electric Co.
