Unidrive "M200" & "M201" AC Open Loop Drives with Optional Communications

****Currently Obsolete by the manufacturer. A replacement Drive is available.

**Legacy Product Replaced by Commander C200

Please contact Microcon for a Replacement****

Unidrive M200 AC drive - Flexible machine integration through communications

0.33hp - 30hp (0.25kW - 22kW)

115V / 230V / 460V / 575V

  • M200 adds useful networking capability, additional I/O and improved motor control performance

  • Easy upgrade for existing Commander SK users

M200 delivers substantial communication and application integration through optional RS485 plus a wide range of industry standard fieldbus and I/O SI modules. Enhances machine up-time and performance with its remote control monitoring and diagnostics possibilities.

Features

Enhance up-time and system flexibility

  • Reduce machine down-time through communications for remote diagnostics

  • Application flexibility through configurable I/O

  • Enhanced system integration through a selection of optional click-in Ethernet, fieldbus and additional I/O SI modules

Improved motor control

  • Greatly enhanced performance through our RFC-A vector algorithm, utilizing closed loop current control

Typical applications

  • Speed control for conveyors, fans, positive displacement pumps and mixers, where their functions are controlled remotely via fieldbus or Ethernet communications

Specifications

Key data

  • Heavy Duty rating: 0.33hp - 30hp (0.25kW - 22kW)

  • Supply phases:

    • Size 1 to 4: 110V drives – 1 phase, 230 and 400V drives - 1 or 3 phase

    • Size 5 upwards: 3 phase

Standard features

Keypad:

  • M200: Fixed LED

  • M201: Fixed LED with speed reference potentiometer

Option slots:

  • 1 (Size 2 and above)

Parameter cloning Via:

  • PC tools

  • SD card

Voltage ratings

100V (100V - 120V ± 10%)

X

200V (200V - 240V ± 10%)

X

400V (380V - 480V ± 10%)

X

575V (500V - 575V ± 10%)

X

690V (500V - 690V ± 10%)



Control mode

Open loop Vector or V/Hz induction motor control

X

Open loop Rotor Flux Control for induction motors (RFC-A)

X

Open loop permanent magnet motor control (RFC-S)



Closed loop Rotor Flux Control for induction motors (RFC-A)



Closed loop permanent magnet motor control (RFC-S)



Active Front End (AFE) power quality convertor





frame size

Dimensions (h X w x d)

Weight kg (lb)


mm

in

kg

lb

1

 160 x 75 x 130
DIN rail mounting:
137 x 75 x 130

6.3 x 3.0 x 5.1
DIN rail mounting:
5.4 x 3.0 x 5.1

 0.75 1.65

2

205 x 75 x 150

DIN rail mounting:
180 x 75 x 150

 8.1 x 3.0 x 5.9
DIN rail mounting:
7.1 x 3.0 x 5.9		 1.0 2.2

3

 226 x 90 x 160 8.9 x 3.5 x 6.3 1.5 3.3

4

 277 x 115 x 175 10.9 x 4.5 x 6.9 3.13 6.9

5

391 x 143 x 192

15.4 x 5.6 x 7.6

7.4

16.3

6

 391 x 210 x 221 15.4 x 8.3 x 8.7 14 30.9

Options

Drive variant

 M201 variant
Provides a speed reference potentiometer keypad to enhance customer choice and ease of use

Keypad

 Remote keypad
All the features of the CI-Keypad LCD, but remote mountable. This allows flexible mounting on the outside of a panel and meets IP66 (NEMA 4)



System Integration Modules - Communications

 SI-PROFIBUS
PROFIBUS interface module

SI-DeviceNet
DeviceNet interface module

SI-CANopen
CANopen interface module supporting various profiles, including several drive profiles

SI-Ethernet
External Ethernet module that supports PROFINET RT*, EtherNet/IP and Modbus TCP/IP and has an integrated web server that can generate emails. The module can be used to provide high speed drive access, global connectivity and integration with IT network technologies, such as wireless networking

SI-EtherCAT*
EtherCAT interface module

System Integration Modules - Additional I/O

SI-I/O
Extended I/O interface module to increase the number of I/O points on a drive. Provides additional: 4 x Digital I/O, 3 x Analog inputs (default)/Digital inputs, 1 x Analog output (default)/Digital input, 2 x Relays.

Drive interface units - Back-up

AI-Back-up Adaptor
Port adaptor that allows the drive to use an SD card for parameter cloning, and an input for 24 V back-up

Drive interface units - Communications

 AI-485 Adaptor
Port adaptor that allows the drive to communicate via RS485





Unidrive M200 Available Sizes

115 VAC, Single Phase 50/60 Hz Input, 230 VAC 3-phase Output

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.33 1.7 0.33 1.7 M200-01100017 6.3 X 3.0 X 5.1 1.7
0.5 2.4 0.5 2.4 M200-01100024
1 4.2 1 4.2 M200-02100042 8.1 X 3.1 X 5.9 2.2
1.5 5.6 1.5 5.6 M200-02100056



230 VAC, Single Phase Input, 3-Phase Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.33 1.7 0.33 1.7 M200-01200017 6.3 X 3.0 5.1 1.7
0.5 2.4 0.5 2.4 M200-01200024
0.75 3.3 0.75 3.3 M200-01200033
1 4.2 1 4.2 M200-01200042
0.5 2.4 0.5 2.4 M200-02200024 8.1 X 3.1 X 5.9 2.2
0.75 3.3 0.75 3.3 M200-02200033
1 4.2 1 4.2 M200-02200042
1.5 5.6 1.5 5.6 M200-02200056
2 7.5 2 7.5 M200-02200075
3 10 3 10 M200-03200100 8.9 X 3.5 X 6.3 3.3
3 13.3 3 13.3 M200-04200133 10.9 X 4.5 X 6.9 6.9



230 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.5 2.4 0.5 2.4 M200-02200024 7.0 X 3.0 X 5.9 2.2
0.75 3.3 0.75 3.3 M200-02200033
1 4.2 1 4.2 M200-02200042
1.5 5.6 1.5 5.6 M200-02200056
2 7.5 2 7.5 M200-02200075
3 10 3 10 M200-03200100 7.9 x 3.5 x 6.3 3.3
3 13.3 3 13.3 M200-04200133

9.7 X 4.5 X 6.9

 6.9
5 17.6 5 17.6 M200-04200176
10 30 7.5 25 M200-05200250 14.9 X 5.6 X 7.9 16.3
15 50 10 33 M200-06200330 14.9 X 8.3 X 8.9 30.9
20 58 15 44 M200-06200440
25 75 20 61 M200-07200610 21.9 X 10.6 X 11.0 61.7
30 94 25 75 M200-07200750 21.9 X 10.6 X 11.0 61.7
40 117 30 83 M200-07200830 21.9 X 10.6 X 11.0 6.17
50 149 40 116 M200-08201160 31.7 X 12.2 X 11.4 114.6
60 180 50 132 M200-08201320 31.7 X 12.2 X 11.4 114.6
75 216 60 176 M200-09201760 43.6 X 12.2 X 11.4 146.6
100 266 75 219 M200-09202190 43.6 X 12.2 X 11.4 146.6
75 216 60 176 M200-09201760E 42.1 X 12.2 X 11.4 101.4
100 266 75 219 M200-0920219E 42.1 X 12.2 X 11.4 101.4



460 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.5 1.3 0.5 1.3 M200-02400013 8.1 x 3.1 x 5.9 2.2
0.75 1.8 0.75 1.8 M200-02400018
1 2.3 1 2.3 M200-02400023
1.5 3.2 1.5 3.2 M200-02400032
2 4.1 2 4.1 M200-02400041
3 5.6 3 5.6 M200-03400056 8.9 x 3.5 x 6.3 3.3
3 7.3 3 7.3 M200-03400073
5 9.4 5 9.4 M200-03400094
7.5 13.5 7.5 13.5 M200-04400135 10.9 x 4.5 x 6.9 6.9
10 17 10 17 M200-04400170
20 30 20 27 M200-05400270 15.4 X 5.6 X 7.9 16.3
20 30 20 30 M200-05400300
25 38 25 35 M200-06400350 15.4 X 8.3 X 9.0 30.9
30 48 30 42 M200-06400420
50 63 30 47 M200-06400470
60 79 50 66 M200-07400660 21.9 X 10.6 X 11.0 61.7
75 94 60 77 M200-07400770
75 112 75 100 M200-07401000
125 155 100 134 M200-08401340 31.7 X 12.2 X 11.4 114.6
150 184 125 157 M200-08401570
150 221 150 180 M200-09402000 43.6 X 12.2 X 11.4 146.6
200 225 150 211 M200-09402240
150 221 150 180 M200-09402000E 42.1 X 12.2 X 11.4 101.4
200 255 150 211 M200-09402240E



575 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
3 3.9 2 3 M200-05500030 15.4 X 5.6 X 7.9 16.3
5 6.1 3 4 M200-05500040
7.5 10 5 6.9 M200-05500069
10 12 7.5 10 M200-06500100 15.4 X 8.3 X 9.0 30.9
15 17 10 15 M200-06500150
20 22 15 19 M200-06500190
25 27 20 23 M200-06500230
30 34 25 29 M200-06500290
40 43 30 34 M200-06500350
50 53 40 44 M200-07500440 21.9 X 10.6 X 11.0 61.7
60 73 50 55 M200-07500550
75 86 60 63 M200-08500630 31.7 X 12.2 X 11.4 114.6
100 108 75 86 M200-08500860
125 125 100 104 M200-09501040 43.6 X 12.2 X 11.4 146.6
150 150 125 131 M200-09501310
125 125 100 104 M200-09501040E 42.1 X 12.2 X 11.4 101.4
150 150 125 131 M200-09501310E



Unidrive M201 Available Sizes

115 VAC, Single Phase 50/60 Hz Input, 230 VAC 3-phase Output

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.33 1.7 0.33 1.7 M201-01100017 6.3 X 3.0 X 5.6 1.7
0.5 2.4 0.5 2.4 M201-01100024
1 4.2 1 4.2 M201-02100042 8.1 X 3.1 X 6.3 2.2
1.5 5.6 1.5 5.6 M201-02100056



230 VAC, Single Phase Input, 3-Phase Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.33 1.7 0.33 1.7 M201-01200017 6.3 X 3.0 5.6 1.7
0.5 2.4 0.5 2.4 M201-01200024
0.75 3.3 0.75 3.3 M201-01200033
1 4.2 1 4.2 M201-01200042
0.5 2.4 0.5 2.4 M201-02200024 8.1 X 3.1 X 6.3 2.2
0.75 3.3 0.75 3.3 M201-02200033
1 4.2 1 4.2 M201-02200042
1.5 5.6 1.5 5.6 M201-02200056
2 7.5 2 7.5 M201-02200075
3 10 3 10 M201-03200100 8.9 X 3.5 X 6.7 3.3
3 13.3 3 13.3 M201-04200133 10.9X 4.5 X 7.3 6.9



230 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.5 2.4 0.5 2.4 M201-02200024 8.1 X 3.1 X 6.3 2.2
0.75 3.3 0.75 3.3 M201-02200033
1 4.2 1 4.2 M201-02200042
1.5 5.6 1.5 5.6 M201-02200056
2 7.5 2 7.5 M201-02200075
3 10 3 10 M201-03200100 8.9 x 3.5 x 6.7 3.3
3 13.3 3 13.3 M201-04200133

10.9 X 4.5 X 7.3

 6.9
5 17.6 5 17.6 M201-04200176
10 30 7.5 25 M201-05200250 15.4 X 5.6 X 7.9 16.3
15 50 10 33 M201-06200330 15.4 X 8.3 X 9.0 30.9
20 58 15 44 M201-06200440
25 75 20 61 M201-07200610 21.9 X 10.6 X 11.0 61.7
30 94 25 75 M201-07200750
40 117 30 83 M201-07200830
50 149 40 116 M201-08201320 31.7 X 12.2 X 11.9 114.6
60 180 50 132 M201-08201320
75 216 60 176 M201-09201760 43.6 X 12.2 X 11.9 146.6
100 266 75 219 M201-09202190
75 216 60 176 M201-09201760E 42.1 X 12.2 X 11.9 101.4
100 266 75 219 M201-09202190E



460 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.5 1.3 0.5 1.3 M201-02400013 7.0 x 3.0 x 5.9 2.2
0.75 1.8 0.75 1.8 M201-02400018
1 2.3 1 2.3 M201-02400023
1.5 3.2 1.5 3.2 M201-02400032
2 4.1 2 4.1 M201-02400041
3 5.6 3 5.6 M201-03400056 7.9 x 3.5 x 6.3 3.3
3 7.3 3 7.3 M201-03400073
5 9.4 5 9.4 M201-03400094
7.5 13.5 7.5 13.5 M201-04400135 9.7 x 4.5 x 6.9 6.9
10 17 10 17 M201-04400170
20 30 20 26 M201-05400270 14.9 X 5.6 X 7.9 16.3
20 30 20 30 M201-05400300
25 38 25 35 M201-06400350 14.9 X 8.3 X 8.9 30.9
30 48 30 42 M201-06400420
50 63 30 46 M201-06400470
60 79 50 66 M201-07400660 21.9 X 10.6 X 11.0 61.7
75 94 60 77 M201-07400770
75 112 75 100 M201-07401000
125 155 100 134 M201-08401340 31.7 X 12.2 X 11.9 114.6
150 184 125 157 M201-08401570
150 221 150 180 M201-09402000 43.6 X 12.2 X 11.9 146.6
200 255 150 211 M201-09402240
150 221 150 180 M201-09402000E 42.1 X 12.2 X 11.9 101.4
200 255 150 211 M201-09402240E



575 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
3 3.9 2 3 M201-05500030 15.4 X 5.6 X 7.9 16.3
5 6.1 3 4 M201-05500040
7.5 10 5 6.9 M201-05500069
10 12 7.5 10 M201-06500100 15.4 X 8.3 X 9.0 30.9
15 17 10 15 M201-06500150
20 22 15 19 M201-06500190
25 27 20 23 M201-06500230
30 34 25 29 M201-06500290
40 43 30 34 M201-06500350
50 53 40 44 M201-07500440 21.9 X 10.6 X 11.0 61.7
60 73 50 55 M201-07500550
75 86 60 63 M201-08500630 31.7 X 12.2 X 11.9 114.6
100 108 75 86 M201-08500860
125 125 100 104 M201-09501040 43.6 X 12.2 X 11.9 146.6
150 150 125 131 M201-09501310
125 125 100 104 M201-09501040E 42.1 X 12.2 X 11.9 101.4
150 150 125 131 M201-09501310E
