Unidrive "M400"  AC Open Loop Drive with PLC, Optional Enhanced Keypad & Dual Safe Torque Off Channels

Unidrive M400 AC drive - Fast set-up and diagnosis with real-text display, plus integrated CODESYS based PLC

0.33hp - 150hp (0.25kW - 110kW)

115V / 230V / 460V / 575V / 690V

  • M400 adds an optional enhanced LCD keypad, precise frequency following and onboard Programmable Logic Control (PLC)

  • Easy upgrade for existing Commander SK users with LogicStick

M400 minimizes machine downtime with its optional intuitive advanced LCD keypad which offers real-text multi-language display for rapid set-up and superior diagnostics. Onboard CODESYS based PLC with a real-time task can be used for simple logic control to enhance drive application capability.


Features

Maximize throughput while protecting people and machinery, and easily meet machine safety requirements

  • Dual STO for safety system integration , eliminating external components

Enhance productivity through integration with the automation system and reduce machine downtime

  • Optional RS485 and a wide range of fieldbus communication SI modules allow remote control and diagnostics across different networks

  • I/O can be configured to accept an encoder or frequency/direction inputs for frequency following

Reduce machine size and cost

  • Compact drive dimensions, among the smallest in class at every power rating

  • Enhanced functionality with onboard PLC programming provides a low cost solution, minimizing additional equipment such as PLCs and safety contactors.

Save energy

  • Low losses up to 98% efficient and low power standby mode

Typical applications

  • Speed control for conveyors, positive displacement pumps, material transport, cutting, woodworking, where fast diagnostics are required


Specifications

Key data

  • Heavy Duty rating: 0.33hp - 150hp (0.25kW - 110kW)

  • Supply phases:

    • Size 1 to 4: 110V drives – 1 phase, 230 and 400V drives - 1 or 3 phase

    • Size 5 upwards: 3 phase

Standard features

Intelligence:

  • Onboard PLC

Feedback:

  • Encoder input – Speed follower

Machine safety:

  • 2 x Safe Torque Off terminals

Keypad:

  • No keypad as standard

Option slots:

  • 1 (Size 2 and above)

Parameter cloningVia:

  • PC tools

  • SD card

Voltage ratings

100V (100V - 120V ± 10%)

X

200V (200V - 240V ± 10%)

X

400V (380V - 480V ± 10%)

X

575V (500V - 575V ± 10%)

X

690V (500V - 690V ± 10%)

X



Control mode

Open loopVector orV/Hz induction motor control

X

Open loop Rotor Flux Control for induction motors (RFC-A)

X

Open loop permanent magnet motor control (RFC-S)



Closed loop Rotor Flux Control for induction motors (RFC-A)



Closed loop permanent magnet motor control (RFC-S)



Active Front End (AFE) power quality convertor





frame size

Dimensions (h X w x d)

Weight kg(lb)

mm

in

kg

lb

1

160 x 75 x 130
DIN rail mounting:
137 x 75 x 130

6.3 x 3.0 x 5.1
DIN rail mounting:
5.4 x 3.0 x 5.1

0.75

1.65

2

205 x 75 x 150

DIN rail mounting:
180 x 75 x 150

8.1 x 3.0 x 5.9
DIN rail mounting:
7.1 x 3.0 x 5.9

1.0

2.2

3

226 x 90 x 160

8.9 x 3.5 x 6.3

1.5

3.3

4

277 x 115 x 175

10.9 x 4.5 x 6.9

3.13

6.9

5

391 x 143 x 192

15.4 x 5.6 x 7.6

7.4

16.3

6

391 x 210 x 221

15.4 x 8.3 x 8.7

14

30.9

7

557 x 270 x 280

21.9 x 10.6 x 11.0

28

61.7

8

803 x 310 x 290

31.6 x 12.2 x 11.4

52

114.6

9*

1108 x 310 x 290

43.6 x 12.2 x 11.4




Options

Keypads

CI-Keypad
Intuitive plain text, multi-language LCD keypad for rapid set-up and superior diagnostics maximizes machine up-time. Novel clip-less fit provides easy removal

Remote keypad
All the features of the CI-Keypad LCD, but remote mountable. This allows flexible mounting on the outside of a panel and meets IP66 (NEMA 4)

System Integration Modules - Communications

SI-PROFIBUS
PROFIBUS interface module

SI-DeviceNet
DeviceNet interface module

SI-CANopen
CANopen interface module supporting various profiles, including several drive profiles

SI-Ethernet
External Ethernet module that supports PROFINET RT*, EtherNet/IP and Modbus TCP/IP and has an integrated web server that can generate emails. The module can be used to provide high speed drive access, global connectivity and integration with IT network technologies, such as wireless networking

SI-EtherCAT*
EtherCAT interface module

System Integration Modules - Additional I/O

SI-I/O
Extended I/O interface module to increase the number of I/O points on a drive. Provides additional: 4 x Digital I/O, 3 x Analog inputs (default)/Digital inputs, 1 x Analog output (default)/Digital input, 2 x Relays

System Integration Modules - Safety

SI-Safety*
Safety module that provides an intelligent, programmable solution to meet the IEC 61800-5-2 functional safety standard

Drive interface units - Back-up

AI-Back-up Adaptor
Port adaptor that allows the drive to use an SD card for parameter cloning, and an input for 24 V back-up

Drive interface units - Communications

AI-485 Adaptor
Port adaptor that allows the drive to communicate via RS485

CI-485 Adaptor
Port adaptor that allows the drive to communicate via RS485. This is commonly used to connect to the remote keypad, or for RS485 communications if there is no AI-485 adaptor fitted or it is already in use







Unidrive M400 Available Sizes


115 VAC, Single Phase 50/60 Hz Input, 230 VAC 3-phase Output

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.33 1.7 0.33 1.7 M400-01100017 6.3 X 3.0 X 5.1 1.7
0.5 2.4 0.5 2.4 M400-01100024
1 4.2 1 4.2 M400-02100042 8.1 X 3.1 X 5.9 2.2
1.5 5.6 1.5 5.6 M400-02100056



230 VAC, Single Phase Input, 3-Phase Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.33 1.7 0.33 1.7 M400-01200017 6.3 X 3.0 5.1 1.7
0.5 2.4 0.5 2.4 M400-01200024
0.75 3.3 0.75 3.3 M400-01200033
1 4.2 1 4.2 M400-01200042
0.5 2.4 0.5 2.4 M400-02200024 8.1X 3.1 X 5.9 2.2
0.75 3.3 0.75 3.3 M400-02200033
1 4.2 1 4.2 M400-02200042
1.5 5.6 1.5 5.6 M400-02200056
2 7.5 2 7.5 M400-02200075
3 10 3 10 M400-03200100 8.9 X 3.5 X 6.3 3.3
3 13.3 3 13.3 M400-04200133 10.9 X 4.5 X 6.9 6.9



230 VAC, 3-Phase Input, 3-Phase Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.5 2.4 0.5 2.4 M400-02200024 8.1 X 3.1 X 5.9 2.2
0.75 3.3 0.75 3.3 M400-02200033
1 4.2 1 4.2 M400-02200042
1.5 5.6 1.5 5.6 M400-02200056
2 7.5 2 7.5 M400-02200075
3 10 3 10 M400-03200100 8.9 x 3.5 x 6.3 3.3
3 13.3 3 13.3 M400-04200133

10.9 X 4.5 X 6.9

6.9
5 17.6 5 17.6 M400-04200176
10 30 7.5 25 M400-05200250 15.4 X 5.6 X 7.9 16.3
15 50 10 33 M400-06200330 15.4 X 8.3 X 9.0 30.9
20 58 15 44 M400-06200440
25 75 20 61 M400-07200610 21.9 X 10.6 X 11.0 61.7
30 94 25 75 M400-07200750
40 117 30 83 M400-07200830
50 149 40 116 M400-08201160 31.7 X 12.2 X 11.4 114.6
60 180 50 132 M400-08201320
75 216 60 176 M400-09201760 43.6 X 12.2 X 11.4 146.6
100 266 75 219 M400-09202190
75 216 60 176 M400-09201760E 42.1 X 12.2 X 11.4 101.4
100 266 75 219 M400-09202170E



230 VAC, 3-Phase Input, 3-Phase Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
75 216 60 176 M400-09201760E 42.1 X 12.2 X 11.4 101.4
100 266 75 219 M400-09202190E 42.1 X 12.2 X 11.4 101.4



460 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
0.5 1.3 0.5 1.3 M400-02400013 8.1 x 3.1 x 5.9 2.2
0.75 1.8 0.75 1.8 M400-02400018
1 2.3 1 2.3 M400-02400023
1.5 3.2 1.5 3.2 M400-02400032
2 4.1 2 4.1 M400-02400041
3 5.6 3 5.6 M400-03400056 8.9 x 3.5 x 6.3 3.3
3 7.3 3 7.3 M400-03400073
5 9.4 5 9.4 M400-03400094
7.5 13.5 7.5 13.5 M400-04400135 10.9 x 4.5 x 6.9 6.9
10 17 10 17 M400-04400170
20 30 20 26 M400-05400270 15.4 X 5.6 X 7.9 16.3
20 31 20 30 M400-05400300
25 38 25 35 M400-06400350 15.4 X 8.3 X 9. 30.9
30 48 30 42 M400-06400420
50 63 30 46 M400-06400470
60 79 50 66 M400-07400660 21.9 X 10.6 X 11.0 61.7
75 94 60 77 M400-07400770
75 112 75 100 M400-07401000
125 155 100 134 M400-08401340 31.7 X 12.2 X 11.4 114.6
150 184 125 157 M400-08401570
150 221 150 180 M400-09402000 43.6 X 12.2 X 11.4 146.6
200 225 150 211 M400-09402240
150 221 150 180 M400-09402000E 42.1 X 12.2 X 11.4 101.4
200 255 150 211 M400-09402240E



460 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
150 221 150 180 M400-09402000E 42.1 X 12.2 X 11.4 101.4
200 255 150 211 M400-09402240E 42.1 X 12.2 X 11.4 101.4



575 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
3 3.9 2 3 M400-05500030 15.4 X 5.6 X 7.9 16.3
5 6.1 3 4 M400-05500040
7.5 10 5 6.9 M400-05500069
10 12 7.5 10 M400-06500100 15.4 X 8.3 X 9.0 30.9
15 17 10 15 M400-06500150
20 22 15 19 M400-06500190
25 27 20 23 M400-06500230
30 34 25 29 M400-06500290
40 43 30 34 M400-06500350
50 53 40 44 M400-07500440 21.9 X 10.6 X 11.00 61.7
60 73 50 55 M400-07500550
75 86 60 63 M400-08500630 31.7 X 12.2 X 11.4 114.6
100 108 75 86 M400-08500860
125 125 100 104 M400-09501040 43.6 X 12.2 X 11.4 146.6
150 150 125 131 M400-09501310
125 125 100 104 M400-09501040E 42.1 X 12.2 X 11.4 101.4
150 150 125 131 M400-09501310E



575 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
125 125 100 104 M400-09501040E 42.1 X 12.2 X 11.4 101.4
150 150 125 131 M400-09501310E 42.1 X 12.2 X 11.4 101.4



690 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
25 23 20 19 M400-07600190 21.9 X 10.6 X 11.0 61.7
30 30 25 24 M400-07600240
40 36 30 29 M400-07600290
50 46 40 38 M400-07600380
60 52 50 44 M400-07600440
75 73 60 54 M400-07600540
100 86 75 63 M400-08600630 31.7 X 12.2 X 11.4 114.6
125 108 100 86 M400-08600860
150 125 125 104 M400-09601040 43.6 X 12.2 X 11.4 146.6
175 155 150 131 M400-09601310
150 125 125 104 M400-09601040E 42.1 X 12.2 X 11.4 101.4
175 155 150 131 M400-09601310E

***Keypads are sold separate.
