Unidrive "M700" , "M701 & "M702" AC Open/Closed Loop Induction/Servo Drive with Ethernet & with Modbus RTU Communications and Single Safe Torque Off Channel



Unidrive M700 AC drive - Class leading induction and permanent magnet servo motor performance, with real-time Ethernet

 Single Drives:

1.0hp – 400hp (0.75kW – 250KW) Heavy Duty

1.0hp – 450hp (0.75kW – 280KW) Normal Duty

Modular Drives:

1.0hp – 4200hp (0.75kW – 2.8MW)

230V / 460V / 575V / 690V

  • M700 adds onboard Ethernet, comprehensive position feedback and high performance control of dynamic permanent magnet servo motors

  • Fully compatible upgrade for existing Unidrive SP users

M700 delivers maximum machine throughput through greater control with single and multi-axis network synchronization. Onboard real-time Ethernet (IEEE 1588 V2), advanced motion control and high speed I/O for position capture enables machine builders to easily create more sophisticated and flexible machines.

Features

Maximize machine productivity through integration with centralized control systems

  • Ethernet IEEE 1588 V2 hardware implementation for maximum synchronization accuracy

  • Integrated dual port Ethernet switch for easy connectivity

  • Up to three SI modules to add position feedback, I/O and fieldbus communications

Maximize machine productivity through shaft performance with any motor technology

  • High bandwidth motor control algorithm for open and closed loop induction, synchronous reluctance and PM servo motors with up to 3,300 Hz current loop bandwidth and 250 Hz speed loop bandwidth

  • Flexible feedback from robust resolvers to high resolution encoders

Flexible universal encoder port

Increase flexibility and reduce system costs through simultaneously connecting up to three* high performance encoder channels as standard. As an example, the drive can interface with a feedback encoder, reference encoder and provide a simulated encoder output without the need for additional option modules.

  • Two universal encoder input channels

    • Support for standard incremental and SinCos encoders, including those with absolute commutation signals

    • Support for communications based encoders with up to 4 Mb rate and line compensation to support long cable lengths of up to 100m

      • Support includes BiSS C, EnDat 2.2, HIPERFACE and SSI

    • Support for Resolver for feedback in harsh environments

  • One simulated encoder output

    • Position reference for CAMs, digital lock and electronic gearbox applications

    • Implemented through hardware to maximize performance

*The functionality is dependent upon the encoder types being used

Onboard PLC and Advanced Motion Controller

Simple onboard CODESYS based PLC with a real-time task for interfacing with the drives 1.5 axis Advanced Motion Controller. Key features include:

  • 250 μs cycle time

  • Motion profile generator

  • Electronic gearbox

  • Interpolated CAM

  • Homing function

  • High speed position freeze

Typical applications

  • Speed and position control for gearing and ratio control, winding (coilers), web handling, metal cutting, flying shear, rotary knife, test stands, printing, packaging machines, textiles, woodworking, tire manufacturing

Specifications

Key data

  • Heavy Duty rating: 1.0hp – 4200hp (0.75kW – 2.8MW)

  • Supply phases: 3 phase

Standard features

Intelligence:

  • Onboard PLC

  • Advanced Motion Controller

Onboard comms:

  • M700 & M702 – Ethernet

  • M701 – RS485

Feedback:

  • 2 x Encoder inputs

  • 1 x Simulated encoder output

Machine safety:

  • M700 & M701 - 1 x Safe Torque Off (STO) terminal

  • M702 – 2 x STO terminals

Keypad:

  • No keypad as standard

Option slots:

  • 3

Parameter Cloning Via:

  • PC tools

  • Smartcard

  • SD card

Voltage ratings

100V (100V - 120V ± 10%)



200V (200V - 240V ± 10%)

X

400V (380V - 480V ± 10%)

X

575V (500V - 575V ± 10%)

X

690V (500V - 690V ± 10%)

X



Control mode

Open loopVector orV/Hz induction motor control

X

Open loop Rotor Flux Control for induction motors (RFC-A)

X

Open loop permanent magnet motor control (RFC-S)

X

Closed loop Rotor Flux Control for induction motors (RFC-A)

X

Closed loop permanent magnet motor control (RFC-S)

X

Active Front End (AFE) power quality convertor

X

SINGLE DRIVES:

frame size

Dimensions (h X w x d)

Weight kg (lb)


mm

in

kg

lb

3

 382 x 83 x 200 15.0 x 3.3 x 7.9 4.5 Max 9.9 Max

4

 391 x 124 x 200 15.4 x 4.9 x 7.9 6.5 14.3

5

391 x 143 x 200

15.4 x 5.6 x 7.6

7.4

16.3

6

 391 x 210 x 227 15.4 x 8.3 x 8.9 14 30.9

7

 557 x 270 x 280 21.9 x 10.6 x 11.0 28 61.7

8

 803 x 310 x 290 31.6 x 12.2 x 11.4 52 114.6

9*

 1108 x 310 x 290 43.6 x 12.2 x 11.4

9†

 1069 x 310 x 288 42.1 x 12.2 x 11.3 46 101.4

10†

 1069 x 310 x 288 42.1 x 12.2 x 11.3 46 101.4

11*†

 1410 x 310 x 310 55.5 x 12.2 x 12.2

† Internal line choke not included

MODULAR DRIVES:

frame size

Dimensions (h X w x d)


mm

in
INVERTER & RECTIFIER

9†

 1069 x 310 x 289 42.1 x 12.2 x 11.4

10†

 1069 x 310 x 289 42.1 x 12.2 x 11.4

11*†

 1410 x 310 x 310 55.5 x 12.2 x 12.2
INVERTER

9

 773 x 310 x 290 30.4 x 12.2 x 11.4

10

 773 x 310 x 290 30.4 x 12.2 x 11.4

11*

 880 x 310 x 310 34.7 x 12.2 x 12.2
RECTIFIER

10†

 6 pulse
355 x 310 x 290		 6 pulse
15.8 x 12.2 x 11.4

11*†

 6 pulse
570 x 310 x 310
12 pulse
570 x 310 x 310		 6 pulse
22.4 x 12.2 x 12.2
12 pulse
22.4 x 12.2 x 12.2

† Internal line choke not included

Drive variants

 M701 - Unidrive SP replacement
Designed to match Control Techniques’ highly popular Unidrive SP feature-set. This includes RS485 communications, 1 x STO, analog and digital I/O, identical control connectors, with Unidrive SP Smartcard parameter sets supported to make upgrading to Unidrive M as simple as possible

M702 - Safety Enhanced
The safety enhanced M700 has 2 x STO, onboard real-time Ethernet and digital I/O; where easy integration with modern control and safety systems is paramount. If analog I/O is required, this can be provided by an SI-I/O option module

Keypads

 Remote keypad
All the features of the CI-Keypad LCD, but remote mountable. This allows flexible mounting on the outside of a panel and meets IP66 (NEMA 4)

KI-Keypad
Plain text, multi-language LCD keypad with up to 4 lines of text for in depth parameter and data descriptions, for enhanced user experience

KI-Keypad RTC
All the features of the KI-Keypad, but with battery operated realtime clock. This allows accurate time stamping of events, aiding diagnostics

System Integration Modules - Feedback

 SI-Encoder
Incremental encoder input interface module. Provides Closed loop Rotor Flux Control for induction motors (RFC-A) on M600

SI-Universal Encoder*
Additional combined encoder input and output interface supporting Incremental, SinCos, HIPERFACE, EnDAT and SSI encoders

System Integration Modules - Communications

 SI-PROFIBUS
PROFIBUS interface module

SI-DeviceNet
DeviceNet interface module

SI-CANopen
CANopen interface module supporting various profiles, including several drive profiles

SI-Ethernet
External Ethernet module that supports PROFINET RT*, EtherNet/IP and Modbus TCP/IP and has an integrated web server that can generate emails. The module can be used to provide high speed drive access, global connectivity and integration with IT network technologies, such as wireless networking

SI-PROFINET RT
PROFINET RT interface module

SI-EtherCAT*
EtherCAT interface module

System Integration Modules - Applications

 SI-Applications Plus
A Unidrive SP SM-Applications compatible module, which allows existing SYPTPro application programs to be re-compiled for Unidrive M700

MCi200
System integration module that provides a second processor, allowing advanced machine control using industry standard CODESYS programming environment

MCi210
System integration module that provides a second processor, allowing advanced machine control using industry standard CODESYS programming environment. Also it has additional memory and a dual port switched Ethernet interface directly on the CODESYS processor, extending machinery control performance and enables the M700 and M800 to have simultaneous connectivity to 2 separate Ethernet networks

System Integration Modules - Additional I/O

SI-I/O
Extended I/O interface module to increase the number of I/O points on a drive. Provides additional: 4 x Digital I/O, 3 x Analog inputs (default)/Digital inputs, 1 x Analog output (default)/Digital input, 2 x Relays

System Integration Modules - Safety

 SI-Safety*
Safety module that provides an intelligent, programmable solution to meet the IEC 61800-5-2 functional safety standard

Drive interface units - Back-up

 Smartcard
The optional Smartcard memory device can be used to back-up parameter sets and basic PLC programs, as well as copying them from one drive to another

SD Card Adaptor
Conversion device that allows an SD card to be inserted into the Smartcard slot, for parameter cloning and application programs

Drive interface units - Communications

 KI-485 Adaptor
This allows the drive to communicate via RS485. This is commonly used for programming if the drive has no keypad

Other hardware

 Remote I/O
Flexible I/O system for remote connectivity

Unidrive M700 Available Sizes

230 VAC, 3-Phase Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
1.5 6.6 1 5 M700-03200050A 15.0 X 3.3 X 7.9 8.8
2 8 1.5 6.6 M700-03200066A
3 11 2 8 M700-03200080A
3 12.7 3 10.6 M700-03200106A
5 18 3 13.7 M700-04200137A 15.4 X 4.9 X 7.9 14.3
7.5 25 5 18.5 M700-04200185A
10 30 7.5 25 M700-05200250A 15.4 X 5.6 X 7.9 16.3
15 50 10 33 M700-06200330A 15.4 X 8.3 X 9.0 30.9
20 58 15 44 M700-06200440A
25 75 20 61 M700-07200610A 21.9 X 10.6 X 11.0 61.7
30 94 25 75 M700-07200750A
40 117 30 83 M700-07200830A
50 149 40 116 M700-08201160A 31.7 X 12.2 X 11.4 114.6
60 180 40 132 M700-08201320A
75 216 60 176 M700-09201760A 43.6 X 12.2 X 11.4 146.6
100 266 75 219 M700-09202190A
75 216 60 176 M700-09201760E 42.1 X 12.2 X 11.4 101.4
100 266 75 219 M700-09202190E
125 325 100 283 M700-10202830E
150 360 125 300 M700-10203000E



230 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
75 216 60 176 M700-09201760E 42.1 X 12.2 X 11.4 101.4
100 266 75 219 M700-09202190E
125 325 100 283 M700-10202830E
150 360 125 300 M700-10203000E



460 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
2 3.4 1 2.5 M700-03400025A 15.0 X 3.3 X 7.9 8.8
2 4.5 1.5 3.1 M700-03400031A
3 6.2 2 4.5 M700-03400045A
5 7.7 3 6.2 M700-03400062A
5 10.4 5 7.8 M700-03400078A 15.0 X 3.3 X 7.9 9.9
7.5 12.3 5 10 M700-03400100A
10 18.5 10 15 M700-04400150A 15.4 X 4.9 X 7.9 14.3
15 24 10 17.2 M700-04400172A
20 30 15 25.4 M700-05400270A 15.4 X 5.6 X 7.9 16.3
20 31 15 30 M700-05400300A
25 38 25 35 M700-06400350A 15.4 X 8.3 X 9.0 30.9
30 48 25 42 M700-06400420A
50 63 25 46 M700-06400470A
60 79 50 66 M700-07400660A 21.9 X 10.6 X 11.00 61.7
75 94 50 77 M700-07400770A
75 112 60 100 M700-07401000A
125 155 100 134 M700-08401340A 31.7 X 12.2 X 11.4 114.6
150 184 100 157 M700-08401570A
150 221 150 180 M700-09402000A 43.6 X 12.2 X 11.4 146.6
200 255 150 211 M700-09402240A
150 221 150 180 M700-09402000E 42.1 X 12.2 X 11.4 101.4
200 255 150 211 M700-10402700E
250 320 200 270 M700-10402700E
300 361 250 320 M700-10403200E
350 437 300 377 M700-11403770E 48.9 X 12.2 X 12.3 138.9
400 487 350 417 M700-11404170E
450 507 400 464 M700-11404640E



460 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
150 221 150 180 M700-09402000E 42.1 X 12.2 X 11.4 101.4
200 255 150 211 M700-09402240E
250 320 200 270 M700-10402700E
300 361 250 307 M700-10403200E
350 437 300 377 M700-11403770E 48.9 X 12.2 X 12.3 138.9
400 487 350 417 M700-11404170E
450 507 400 464 M700-11404640E



575 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
3 3.9 2 3 M700-05500030A 15.4 X 5.6 X 7.9 16.3
5 6.1 3 4 M700-05500040A
7.5 10 5 6.9 M700-05500069A
10 12 7.5 10 M700-06500100A 15.4 X 8.3 X 9.0 30.9
15 17 10 15 M700-06500150A
20 22 15 19 M700-06500190A
25 27 20 23 M700-06500230A
30 34 25 29 M700-06500290A
40 43 30 34 M700-06500350A
50 53 40 44 M700-07500440A 21.9 X 10.6 X 11.00 61.7
60 73 50 55 M700-07500550A
75 86 60 63 M700-08500630A 31.7 X 12.2 X 11.4 114.6
100 108 75 86 M700-08500860A
125 125 100 104 M700-09501040A 43.6 X 12.2 X 11.4 146.6
150 150 125 131 M700-09501310A
125 125 100 104 M700-09501040E 42.1 X 12.2 X 11.4 101.4
150 150 125 131 M700-09501310E
200 200 150 152 M700-10501520E
200 200 200 190 M700-10501900E
250 248 200 200 M700-11502000E 48.9 X 12.2 X 12.3 138.9
300 288 250 254 M700-11502540E
350 315 300 285 M700-11502850E



575 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
125 125 100 104 M700-09501040E 42.1 X 12.2 X 11.4 101.4
150 150 125 131 M700-09501310E
200 200 150 152 M700-10501520E
200 200 200 190 M700-10501900E
250 248 200 200 M700-11502000E 48.9 X 12.2 X 12.3 138.9
300 288 250 254 M700-11502540E
350 315 300 285 M700-11502850E



690 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
25 23 20 19 M700-07600190A 21.9 X 10.6 X 11.0 61.7
30 30 25 24 M700-07600240A
40 36 30 29 M700-07600290A
50 46 40 38 M700-07600380A
60 52 50 44 M700-07600440A
75 73 60 54 M700-07600540A
100 86 75 63 M700-08600630A 31.7 X 12.2 X 11.4 114.6
125 108 100 86 M700-08600860A
150 125 125 104 M700-09601040A 43.6 X 12.2 X 11.4 146.6
175 155 150 131 M700-09601310A
150 125 125 104 M700-09601040E 42.0 X 12.2 X 11.4 101.4
175 155 150 131 M700-09601310E
200 172 175 150 M700-10601500E
250 197 200 178 M700-10601780E
250 225 250 210 M700-11602100E 48.9 X 12.2 X 12.3 138.9
300 275 250 238 M700-11602380E
400 305 300 263 M700-11602630E



690 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
150 125 125 104 M700-09601040E 42.1 X 12.2 X 11.4 101.4
175 155 150 131 M700-09601310E
200 172 175 150 M700-10601500E
250 197 200 178 M700-10601780E
250 225 250 210 M700-11602100E 48.9 X 12.2 X 12.3 138.9
300 275 250 238 M700-11602380E
400 305 300 263 M700-11602630E

***Keypads are sold separate.

Unidrive M701 Available Sizes

230 VAC, 3-Phase Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
1.5 6.6 1 5 M701-03200050A 15.0 X 3.3 X 7.9 8.8
2 8 1.5 6.6 M701-03200066A
3 11 2 8 M701-03200080A
3 12.7 3 10.6 M701-03200106A
5 18 3 13.7 M701-04200137A 15.4 X 4.9 X 7.9 14.3
7.5 25 5 18.5 M701-04200185A
10 30 7.5 25 M701-05200250A 15.4 X 5.6 X 7.9 16.3
15 50 10 33 M701-06200330A 15.4 X 8.3 X 9.0 30.9
20 58 15 44 M701-06200440A
25 75 20 61 M701-07200610A 21.9 X 10.6 X 11.0 61.7
30 94 25 75 M701-07200750A
40 117 30 83 M701-07200830A
50 149 40 116 M701-08201160A 31.7 X 12.2 X 11.4 114.6
60 180 40 132 M701-08201320A
75 216 60 176 M701-09201760E 43.6 X 12.2 X 11.4 146.6
100 266 75 219 M701-09201760E
75 216 60 176 M701-09201760E 42.1 X 12.2 X 11.4 101.4
100 266 75 219 M701-09201760E
125 325 100 283 M701-10202830E
150 360 125 300 M701-10203000E



230 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
75 216 60 176 M701-09201760E 42.1 X 12.2 X 11.4 101.4
100 266 75 219 M701-09202190E
125 325 100 283 M701-10202830E
150 360 125 300 M701-10203000E



460 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
2 3.4 1 2.5 M701-03400025A 15.0 X 3.3 X 7.9 8.8
2 4.5 1.5 3.1 M701-03400031A
3 6.2 2 4.5 M701-03400045A
5 7.7 3 6.2 M701-03400062A
5 10.4 5 7.8 M701-03400078A 15.0 X 3.3 X 7.9 9.9
7.5 12.3 5 9.2 M701-03400100A
10 18.5 10 15 M701-04400150A 15.4 X 4.9 X 7.9 14.3
15 24 10 17.2 M701-04400172A
20 30 15 25.4 M701-05400270A 15.4 X 5.6 X 7.9 16.3
20 31 15 30 M701-05400300A
25 38 25 35 M701-06400350A 15.4 X 8.3 X 9.0 30.9
30 48 25 42 M701-06400420A
50 63 25 46 M701-06400470A
60 79 50 66 M701-07400660A 21.9 X 10.6 X 11.00 61.7
75 94 50 77 M701-07400770A
75 112 60 100 M701-07401000A
125 155 100 134 M701-08401340A 31.7 X 12.2 X 11.4 114.6
150 184 100 157 M701-08401570A
150 221 150 180 M701-09402000A 43.6 X 12.2 X 11.4 146.6
200 255 150 211 M701-09402240E
150 221 150 180 M701-09402000E 42.1 x 12.2 x 11.4 101.4
200 255 150 211 M701-09402240E
250 320 200 270 M701-10402700E
300 361 250 307 M701-10403200E
350 437 300 377 M701-11403770E 48.9 X 12.2 X 12.3 138.9
400 487 350 417 M701-11404170E
450 507 400 464 M701-11404640E



460 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
150 221 150 180 M701-09402000E 42.1 X 12.2 X 11.4 101.4
200 255 150 211 M701-09402240E
250 320 200 270 M701-10402700E
300 361 250 307 M701-10403200E
350 437 300 377 M701-11403770E 48.9 X 12.2 X 12.3 138.9
400 487 350 417 M701-11404170E
450 507 400 464 M701-11404640E



575 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
3 3.9 2 3 M701-05500030A 15.4 X 5.6 X 7.9 16.3
5 6.1 3 4 M701-05500040A
7.5 10 5 6.9 M701-05500069A
10 12 7.5 10 M701-06500100A 15.4 X 8.3 X 9.0 30.9
15 17 10 15 M701-06500150A
20 22 15 19 M701-06500190A
25 27 20 23 M701-06500230A
30 34 25 29 M701-06500290
40 43 30 34 M701-06500350A
50 53 40 44 M701-07500440A 21.9 X 10.6 X 11.00 61.7
60 73 50 55 M701-07500550A
75 86 60 63 M701-08500630A 31.7 X 12.2 X 11.4 114.6
100 108 75 86 M701-08500860A
125 125 100 104 M701-09501040A 43.6 X 12.2 X 11.4 146.6
150 150 125 131 M701-09501310A
125 125 100 104 M701-09501040E 42.1 X 12.2 X 11.4 101.4
150 150 125 131 M701-09501310E
200 200 150 152 M701-10501520E
200 200 200 190 M701-10501900E
250 248 200 200 M701-11502000E 48.9 X 12.2 X 12.3 138.9
300 288 250 254 M701-11502000E
350 315 300 285 M701-11502850E



575 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
125 125 100 104 M701-09501040E 42.1 X 12.2 X 11.4 101.4
150 150 125 131 M701-09501310E
200 200 150 152 M701-10501520E
200 200 200 190 M701-10501900E
250 248 200 200 M701-11502000E 48.9 X 12.2 X 12.3 138.9
300 288 250 254 M701-11502540E
350 315 300 285 M701-11502850E



690 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
25 23 20 19 M701-07600190 21.9 X 10.6 X 11.0 61.7
30 30 25 24 M701-07600240
40 36 30 29 M701-07600290
50 46 40 38 M701-07600380
60 52 50 44 M701-07600440
75 73 60 54 M701-07600540
100 86 75 63 M701-08600630 31.7 X 12.2 X 11.4 114.6
125 108 100 86 M701-08600860
150 125 125 104 M701-09601040 43.6 X 12.2 X 11.4 146.6
175 155 150 131 M701-09601310
150 125 125 104 M701-09601040E 42.1 X 12.2 X 11.4 101.4
175 155 150 131 M701-09601310E
200 172 175 150 M701-10601500E
250 197 200 178 M701-10601780E
250 225 250 210 M701-11602100E 48.9 X 12.2 X 12.3 138.9
300 275 250 238 M701-11602380E
400 305 300 263 M701-11602630E



690 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
150 125 125 104 M701-09601040E 42.1 X 12.2 X 11.4 101.4
175 155 150 131 M701-09601310E
200 172 175 150 M701-10601500E
250 197 200 178 M701-10601780E
250 225 250 210 M701-11602100E 48.9 X 12.2 X 12.3 138.9
300 275 250 238 M701-11602380E
400 305 300 263 M701-11602630E

***Keypads are sold separate.

Unidrive M702 Available Sizes

230 VAC, 3-Phase Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
1.5 6.6 1 5 M702-03200050A 15.0X 3.3 X 7.9 8.8
2 8 1.5 6.6 M702-03200066A
3 11 2 8 M702-03200080A
3 12.7 3 10.6 M702-03200106A
5 18 3 13.7 M702-04200137A 15.4 X 4.9 X 7.9 14.3
7.5 25 5 18.5 M702-04200185A
10 30 7.5 25 M702-05200250A 15.4 X 5.6 X 7.9 16.3
15 50 10 33 M702-06200330A 15.4 X 8.3 X 9.0 30.9
20 58 15 44 M702-06200440A
25 75 20 61 M702-07200610A 21.9 X 10.6 X 11.0 61.7
30 94 25 75 M702-07200750A
40 117 30 83 M702-07200830A
50 149 40 116 M702-08201160A 31.7 X 12.2 X 11.4 114.6
60 180 50 132 M702-08201320A
75 216 60 176 M702-10201760E 43.6 X 12.2 X 11.4 146.6
100 266 75 219 M702-10202190E
75 216 60 176 M702-09201760E 42.1 X 12.2 X 11.4 101.4
100 266 75 219 M702-09202190E
125 325 100 283 M702-10202830E
150 360 125 300 M702-10203000E

230 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
75 216 60 176 M702-09201760E 42.1X 12.2 X 11.4 101.4
2 8 1.5 6.6 M702-09202190E
3 11 2 8 M702-10202830E
3 12.7 3 10.6 M702-10203000E

460 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
2 3.4 1 2.5 M702-03400025A 15.0 X 3.3 X 7.9 8.8
2 4.5 1.5 3.1 M702-03400031A
3 6.2 2 4.5 M702-03400045A
5 7.7 3 6.2 M702-03400062A
5 10.4 5 7.8 M702-03400078A 15.0 X 4.9X 7.9 9.9
7.5 12.3 5 9.2 M702-03400100A
10 18.5 10 15 M702-04400150A 15.4 X 4.9 X 7.9 14.3
15 24 10 17.2 M702-04400172A
20 30 15 25.4 M702-05400270A 15.4 X 5.6 X 7.9 16.3
20 31 15 30 M702-05400300A
25 38 25 35 M702-06400350A 15.4 X 8.3 X 9.0 30.9
30 48 25 42 M702-06400420A
50 63 25 46 M702-06400470A
60 79 50 66 M702-07400660A 21.9 X 10.6 X 11.00 61.7
75 94 50 77 M702-07400770A
75 112 60 100 M702-07401000A
125 155 100 134 M702-08401340A 31.7 X 12.2 X 11.4 114.6
150 184 100 157 M702-08401570A
150 221 150 180 M702-10402000A 43.6 X 12.2 X 11.4 146.6
200 266 150 211 M702-10402240A
150 221 150 180 M702-09402000E 42.1 x 12.2 x 11.4 101.4
200 255 150 211 M702-09402240E
250 320 200 270 M702-10402700E
300 361 250 307 M702-10403200E
350 437 300 377 M702-11403770E 48.9 x 12.2 x 12.3 138.9
400 487 350 417 M702-11404170E
450 507 400 464 M702-11404640E

460 VAC, 3-Phase Input and Output, 50/60 Hz Input No Dynamic Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
150 221 150 180 M702-09402000E 42.1 X 12.2 X 11.4 101.4
200 266 150 211 M702-09402240E
250 320 200 270 M702-10402700E
300 361 250 307 M702-10403200E
350 437 300 377 M702-11403770E 48.9 X 12.2 X 12.3 138.9
400 487 350 417 M702-11404170E
450 507 400 464 M702-11404640E

575 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
3 3.9 2 3 M702-05500030A 15.4 X 5.6 X 7.9 16.3
5 6.1 3 4 M702-05500040A
7.5 10 5 6.9 M702-05500069A
10 12 7.5 10 M702-06500100A 15.4 X 8.3 X 9.0 30.9
15 17 10 15 M702-06500150A
20 22 15 19 M702-06500190A
25 27 20 23 M702-06500230A
30 34 25 29 M702-06500290A
40 43 30 34 M702-06500350A
50 53 40 44 M702-07500440A 21.6 X 10.6 X 11.00 99.2
60 73 50 55 M702-07500550A
75 86 60 63 M702-08500630A 30.9 X 12.2 X 11.4 110.2
100 108 75 86 M702-08500860A
125 125 100 104 M702-10501040A 43.6 X 12.2 X 11.4 146.6
150 150 125 131 M702-10501310A
125 125 100 104 M702-09501010E 42.1 X 12.2 X 11.4 101.4
150 150 125 131 M702-09501310E
200 200 150 152 M702-10501520E
200 200 200 190 M702-10501900E
250 248 200 200 M702-11502000E 48.9 X 12.2 X 12.3 138.9
300 288 250 254 M702-11502540E
350 315 300 285 M702-11502850E

575 VAC, 3-Phase Input and Output, 50/60 Hz Input No Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
125 125 100 104 M702-09501040E 42.1 X 12.2 X 11.4 101.4
150 150 125 131 M702-09501310E
200 200 150 152 M702-10501520E
200 200 200 190 M702-10501900E
250 248 200 200 M702-11502000E 48.9 X 12.2 X 12.3 138.9
300 288 250 254 M702-11502540E
350 315 300 285 M702-11502850E

690 VAC, 3-Phase Input and Output, 50/60 Hz Input

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
25 23 20 19 M702-07600190A 21.6 X 10.6 X 11.0 61.7
30 30 25 24 M702-07600240A
40 36 30 29 M702-07600290A
50 46 40 38 M702-07600380A
60 52 50 44 M702-07600440A
75 73 60 54 M702-07600540A
100 86 75 63 M702-08600630A 31.7 X 12.2 X 11.4 114.6
125 108 100 86 M702-08600860A
150 125 125 104 M702-10601040A 43.6 X 12.2 X 11.4 146.6
175 155 150 131 M702-10601310A
150 125 125 104 M702-09601040E 42.1 X 12.2 X 11.4 101.4
175 155 150 131 M702-09601310E
200 172 175 150 M702-10601500E
250 197 200 178 M702-10601780E
250 225 250 210 M702-11602100E 48.9 X 12.2 X 12.3 138.9
300 275 250 238 M702-11602380E
400 305 300 263 M702-11602630E

690 VAC, 3-Phase Input and Output, 50/60 Hz Input No Braking Transistor

Normal Duty
Heavy Duty Base Order Code Dimensions (H x W x D) (in) Weight (lbs)
HP Amps HP Amps
150 125 125 104 M702-09601040E 42.1 X 12.2 X 11.4 101.4
175 155 150 131 M702-09601310E
200 172 175 150 M702-10601500E
250 197 200 178 M702-10601780E
250 225 250 210 M702-11602100E 48.9 X 12.2 X 12.3 138.9
300 275 250 238 M702-11602380E
400 305 300 263 M702-11602630E

***Keypads are sold separate.

Home / Contact Us / Products / Service / Sales /Supported Product / Powertec Support / Serviced Products / Feedback



Microcon Technologies Inc.

1105 Crestlawn Drive, Unit # D8 & D9

Mississauga, Ontario L4W 1A7 Canada

Tel: (905) 602-4770

Fax: (905) 602-4779

e-mail: sales@microcontechnologies.com

Website: www.microcontechnologies.com
